At Jogani Valves we know that things have to work when it comes to industrial operations. We are one of the companies that make rubber-lined butterfly valves in Ahmedabad. We work hard to make valves that can handle tough situations. Our rubber-lined butterfly valves are not parts; they are a way to make sure your pipelines are safe and work well.

We make good rubber-lined flanged butterfly valve options. These are designed to stop leaks and resist things that can cause damage. You will not have to fix them often.

Key Features of Our RUBBER-LINED BUTTERFLY VALVE:

Zero-leakage performance It is really good because the rubber lining is made to fit.
Corrosion Resistant: Designed to handle aggressive fluids and harsh industrial.
Easy installation: Installing this thing is really easy. It has a flanged design.
Durable Operation: Built for high-cycle applications with low torque requirements.
Suitable for pneumatic and hydraulic systems
Zero-Leakage Performance will always have a seal.

If you are in charge of water treatment or chemical processing or HVAC systems, our rubber-lined flanged butterfly valve options will help you control the flow of things easily.

When you pick us to make your rubber-lined flanged butterfly valve, you are picking a company that makes things precisely, and our products will last a long time.

You can trust Jogani Valves to keep your flow of things, and your work will keep running without stopping.

TECHNICAL DETAIL
DESIGN TYPE	CENTER DISC DESIGN RUBBER LINED
MFG. STANDARD	BS 5155, API 609 & AWWA 504
TESTING STANDARD	API 598/ BS 6755 Part-I
FACE TO FACE STANDARD	BS 5155, API 609 & AWWA 504 / ANSI B 16.10
PRESSURE & TEMPERATURE RATING	ASME B 16.34
PRESSURE CLASS	150# PN10, PN 16
VALVE SIZE	1½” To 40” (40 mm TO 1000 mm)
END CONNECTIONS	WAFER TYPE
FLANGE DRILLING	150#, PN10, PN 16 BS 10 TABLE D / E / F / H
VALVE SEAT LEAKAGE	CLASS VI (Zero Leakage)
MATERIAL OF CONSTRUCTIONS	CI TO IS 210 GR. FG 200 ASTM A 216 GR. WCB ASTM A 351 GR. CF8 / CF8M / CF3 / CF3M **Also Other Special Alloy available on request.
OPERATIONS	HAND WHEEL / GEAR PNEUMATIC / ELECTRICAL ACTUATOR **Also Other Special Operation available on request.
