At Jogani Valves we are really proud of what we do. We make sure that our flow control solutions really work for your business. We are a company that makes dual plate check valves in Ahmedabad. Our valves are small and lightweight. They stop the water from flowing without being too big and heavy like the old models. We design Jogani Valves flow control solutions to be good for your business.

Our dual plate check valves are made to prevent backflow. Our DUAL PLATE CHECK VALVE series is made to work in the real world. We know that it is very important to keep the system working, so our DUAL PLATE CHECK VALVE is designed to reduce water hammer and loss of pressure.

Key Features of Our DUAL PLATE CHECK VALVE:

Dual plate construction reduces overall valve weight and space requirement.
Spring-assisted plates close rapidly, minimizing backflow and reducing.
A streamlined flow path ensures smooth fluid movement with minimal pressure.
Manufactured using high-quality cast iron, carbon steel, or stainless steel
Precision-fitted plates and resilient sealing surfaces ensure tight shut-off.
Simple internal design allows easy inspection and minimal maintenance over time.

If you need a company to make a DUAL PLATE CHECK VALVE for you or if you are looking for DUAL PLATE CHECK VALVE sellers, in Ahmedabad.

We have the DUAL PLATE CHECK VALVE you need. We know what we are doing to help you with your projects. We are recognized among the leading dual-plate check valve manufacturers in Ahmedabad because we prioritize durability and precision testing.

When you choose Jogani Valves, you aren’t just buying a component; you are investing in a reliable solution that keeps your industrial pipelines running smoothly and safely.

TECHNICAL DETAIL
DESIGN TYPE	WAFER TYPE LUGGED END DOUBLE FLANGED END
MFG. STANDARD	API 594 / API 6D
TESTING STANDARD	API 598 / API 6D / BS 6755 PART 1
FACE TO FACE STANDARD	ASME B 16.10 / API 594 / API 6D
PRESSURE CLASS	150#, 300# PN10, PN 16, PN 25, PN 40
VALVE SIZE	2” To 48” (50 mm TO 1200 mm)
END CONNECTIONS	WAFER TYPE, FLANGELESS SANDIWCH PATTERN DOUBLE FLANGED END
MOUNTING BETWEEN	150#, 300# PN10, PN 16, PN 25, PN 40 BS 10 TABLE D / E / F / H **Between any standard flanges
MATERIAL OF CONSTRUCTIONS	CI TO IS 210 GR. FG 200 ASTM A 216 GR. WCB ASTM A 351 GR. CF8 / CF8M / CF3 / CF3M **Also Other Special Alloy available on request.
